The Vault/

Scroll Progress Bar

Scroll Progress Bar

Documentation

Webflow

Code

Setup: External Scripts

External Scripts in Webflow

Make sure to always put the External Scripts before the Javascript step of the resource.

In this video you learn where to put these in your Webflow project? Or how to include a paid GSAP Club plugin in your project?

HTML

Copy
<script src="https://cdn.jsdelivr.net/npm/gsap@3.12.5/dist/gsap.min.js"></script>
<script src="https://cdn.jsdelivr.net/npm/gsap@3.12.5/dist/ScrollTrigger.min.js"></script>

<!-- Optional if you want to have the 'click to scroll to' functionality-->
<script src="https://cdn.jsdelivr.net/npm/gsap@3.12.5/dist/ScrollToPlugin.min.js"></script>

Step 1: Copy structure to Webflow

Copy structure to Webflow

In the video below we described how you can copy + paste the structure of this resource to your Webflow project.

Copy to Webflow

Webflow structure is not required for this resource.

Step 1: Add HTML

HTML

Copy
<div class="progress-bar-wrap">
  <div class="progress-bar"></div>
</div>

HTML structure is not required for this resource.

Step 2: Add CSS

CSS

Copy
.progress-bar-wrap {
  z-index: 10;
  cursor: pointer;
  width: 100%;
  height: 1.5rem;
  transition: background-color .2s;
  position: fixed;
  inset: 0% 0% auto;
}

.progress-bar-wrap:hover {
  background-color: #0000000d;
}

.progress-bar {
  transform-origin: 0%;
  transform-style: preserve-3d;
  background-color: #ff4c24;
  width: 100%;
  height: 100%;
  transform: scale3d(0, 1, 1);
}

Step 2: Add custom Javascript

Custom Javascript in Webflow

In this video, Ilja gives you some guidance about using JavaScript in Webflow:

Step 2: Add Javascript

Step 3: Add Javascript

Javascript

Copy
gsap.registerPlugin(ScrollTrigger,ScrollToPlugin);

document.addEventListener("DOMContentLoaded", ()=> {

  const progressBar = document.querySelector('.progress-bar');
  const progressBarWrap = document.querySelector('.progress-bar-wrap');

  // Animate the progress bar as you scroll
  gsap.to(progressBar, {
    scaleX: 1,
    ease: 'none', // no ease, we control smoothness with the 'scrub' property
    scrollTrigger: {
      trigger: document.body, // Track the entire page
      start: 'top top',
      end: 'bottom bottom',
      scrub: 0.5, // control the amount of time it takes for the bar to catch up with scroll position
    },
  });

  // Click listener to scroll to a specific position, feel free to remove if you dont want it!
  progressBarWrap.addEventListener('click', (event) => {
    const clickX = event.clientX;
    const progress = clickX / progressBarWrap.offsetWidth;
    const scrollPosition = progress * (document.body.scrollHeight - window.innerHeight);

    gsap.to(window, {
      scrollTo: scrollPosition,
      duration: 0.725,
      ease: 'power3.out',
    });
  });

})

Step 3: Add custom CSS

Step 2: Add custom CSS

Custom CSS in Webflow

Curious about where to put custom CSS in Webflow? Ilja explains it in the below video:

CSS

Copy

Implementation

Click-to-scroll option

For demo purposes, we've added a click listener on the progress-bar-wrap. This is of course optional, so if you don't want this feature, feel free to remove the entire click event listener and remove the GSAP ScrollToPlugin.

Resource Details

GSAP
Navigation
Scrolling
Script

Original source

Osmo

Creator Credits

We always strive to credit creators as accurately as possible. While similar concepts might appear online, we aim to provide proper and respectful attribution.
